Securia Pro DVR hibrid rögzítő 5MP 16 csatornás A6916S-5MP
- Felbontás 5 MPx
- Csatornák száma 16
- Videó bemenet analóg
- Mozgásérzékelés igen
| Kategória: | AHD videó rögzítő (DVR) |
|---|---|
| Jótállás: | 2 év |
| Súly: | 0.5 kg |
| Mobil alkalmazás: | XMEye,Securia Pro |
| Felbontás: | 5MP |
| Kamerák száma: | 16 |
-
- Support VGA, HDMI full HD output simultaneously;
- Support ONVIF; access third party;
- Support AHD, TVI ,CVI,CVBS,IPHD video input;
- Support Web, CMS, center platform management software XMEYE, provide SDK development;
- Support multiple cloud technology, network penetration, alarm information pushed to your phone and other functions;
- Support various mobile monitoring (iPhone, Android);
- Remote Access, With DNS (ARSP),easy to monitor remotely;
Specification:
|
|
Model |
A6916S-5MP |
|
System |
Main processor |
Technical grade embedded microprocessor NT98336 |
|
Operating system |
Embedded LINUX operating system |
|
|
System resource |
Multi-channel real-time recording synchronously, multi-channel real-time playback, multi-channel multi-user network operation, USB back up. |
|
|
Interface |
Operation interface |
16bit real color GUI interface support mouse operation |
|
Display screen |
1/4/8 screen (take analog channel as an example, other is base on the selected channel mode) |
|
|
?? |
Video standard |
PAL/NTSC |
|
Image encode |
H.265(High Profile) |
|
|
Monitor quality |
4K |
|
|
Playback quality |
4*8M(4FPS)/16*5M(6FPS)(6IN1) |
|
|
Decode capability |
16*4K @4fps(6 in 1)/16*5M@6fps(6 in 1)/ 16*4M@9fps(6 in 1)/16*3M@10fps(6 in 1)/16*1080P@16fps(6 in 1) |
|
|
Encode capability |
16*4K @4fps(6 in 1)/16*5M@6fps(6 in 1)/ 16*4M@9fps(6 in 1)/16*3M@10fps(6 in 1)/16*1080P@16fps(6 in 1) |
|
|
Multi-mode video input |
AHD: 16*4K/16*5M NVR: 16*4K/16*5M |
|
|
Motion detection |
Each channel can set 192(16*12)detection area;can set multi-level of flexibility (for local analog channel only) |
|
|
Audio |
Audio compression |
G711A |
|
Bidirectional talk |
support |
|
|
Record and playback |
Record mode |
manual>alarm>motion detection>timing |
|
Local playback |
1-9ch playback synchronously (take local analog input for example, other is depended on the selected channel mode) |
|
|
Video search |
time?date?event?channel search |
|
|
Storage and back up |
Space occupation |
Video:CIF 4~5G/day*channel, D1 16~20G/day*channel; |
|
Video storage |
Local HDD ?Network |
|
|
Back up mode |
Network backup?USB portable HDD?USB imprint?SATA imprint |
|
|
Interface |
Video input |
16CH BNC(1.0Vp-p,75?) |
|
Video output |
1CH VGA,1CH HDMI |
|
|
Audio input |
2CH RCA |
|
|
Audio output |
1CH RCA(200-3000mV,5K?) |
|
|
Alarm input |
No |
|
|
Alarm output |
No |
|
|
Network port |
RJ45 10M/100M/1000M self-adaptive Ethernet port |
|
|
PTZ control |
1 RS485;support multi kinds of PTZ protocol |
|
|
USB port |
2*USB2.0 |
|
|
HDD port |
1SATA ports(each max to 8TB) |
|
|
Wireless port |
3G?WIFI(extension via USB port) |
|
|
other |
Power |
12V/4A |
|
Consumption |
<15W(not including HDD) |
|
|
Temperature |
0°C-+55°C |
|
|
Humidity |
10%-90% |
|
|
Atmosphere pressure |
86kpa-106kpa |
|
|
Dimension |
L255*W230*H45MM |
|
|
Weight |
1.5KG |
